| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | SAFEGAS |
| 인증: | Chinese EX certificate |
| 모델 번호: | Sky8000 |
| 최소 주문 수량: | 1 |
| 가격: | 협상 가능 |
| 포장 세부 사항: | 판지 상자 |
| 배달 시간: | 10 일 |
| 지불 조건: | t/t |
| 공급 능력: | 한 달에 300 조각 |
| 가스 감지: | O2, CO2, CO, NO, NO2, SO2, VOC 등 | 탐지 원리: | 가스 유형 및 적용에 따라 다릅니다 |
|---|---|---|---|
| 범위를 측정하십시오: | 애플리케이션에 따라 특정합니다 | 해결: | 애플리케이션에 따라 특정합니다 |
| 표시하다: | 가스 공식, 실시간 데이터, 실시간 곡선, 배터리, 시간, 펌프 상태, 무선 상태, 프린터 상태 | 경보: | 디스플레이의 버저, 빨간색 LED 및 알람 상태, 오류 경보, 낮은 배터리 알람 |
| 데이터 저장: | 독립적 인 SD 메모리 카드, 표준 32G, 측정 데이터는 자동으로 기록 될 수 있으며 사용자 정의 가능한 레코드 시간 간격 | 데이터 전송 (선택 사항): | RS485 신호 출력, PC 소프트웨어와 함께 USB 인터페이스 데이터 전송은 스토리지, 분석 및 인쇄 데이터를 다운로드 할 수 있습니다. |
| 인쇄 기능 (선택 사항): | 내부 휴대용 프린터 또는 외부 Bluetooth 프린터가있는 선택 사항 | 콘텐츠 인쇄 (선택 사항): | 날짜, 시간, 가스, 농도, 통계, 단위 |
| 보증: | 12 개월 | ||
| 강조하다: | built-in pump gas detector,multi-layer filtering gas detector,fast response gas detector |
||
| Parameter | Details |
|---|---|
| Gas Detected | O2, CO2, CO, NO, NO2, SO2, VOC, etc to be specified according to application |
| Detection Principle | Depend on gas type and application |
| Measure range | Specified according to application |
| Resolution | Specified according to application |
| Display | Gas formula, real-time data, real-time curve, battery, time, pump condition, wireless status, printer status |
| Alarm | Buzzer, red LED and alarm status on the display, fault alarm, low battery alarm |
| Data storage | Independent SD memory card, standard 32G, measurement data can be record automatically, customizable record time interval |
| Data transmission (Optional) | RS485 signal output, USB interface data transmission, with PC software, can download storage, analyze and print data |
| Print function (Optional) | Optional with internal portable printer or external bluetooth printer |
| Print content (Optional) | Date, Time, Gas, Concentration, Stat, Unit |
| Charger | Standard Micro-USB charging port. With 9V/2A charger |
| Language | Chinese/English |
| Network frequency | 2.4G high frequency |
| Wireless transmission distance | Bluetooth is less than 10m, and WIFI outdoor single point is less than 500m |
| Battery | Large capacity rechargeable lithium battery, 5200mAh working hours are more than 32h with single gas and 24h with six gases together |
| Precision | ≤±2%F.S (Higher precision can be customized) |
| Pump flow rate | 500ML/Min |
| Working Humidity | 0~95%RH (no condensation) (optional filter device is available if high humidity) |
| Temperature | -40℃~+70℃, Optional gas sampling gun, can detect up to 1200 degrees gas concentration |
| Screen | 3.5-inch hd LCD screen with resolution 320*480 |
| IP grade | IP66 |
| Explosion-proof | Ex ic IIC T3 Gc |
| Warranty | 12 months |
| Size | (H*W*D) 260*230*120mm |
| Weight | 3700g |
Established in 2010, Shenzhen Yuante Technology Co., Limited is a company that focuses on the design, production and sales of high-end gas detection equipment and system for 16 years. With gas detector as the core product, we have completed production line and solutions according to different industries, such as Oil, Chemical, Medicine, Energy, Environmental Protection, Electronic, Municipal Engineering, Agriculture and Forestry, Household Appliances, etc.
For years, Yuante always insists on the management concept: Market is orientation; Innovation is motivation; Quality to survival; Development to growth. With friendly, open and strict corporate culture and standardized management, Yuante gathers a lot of talents, and builds up the management team and R&D team.
The essence of a detector is the accuracy and faster response. Depending on years of measurement experience and unique solutions, through independent research and development, cooperative development and learning overseas latest technology, Yuante's products are advanced beyond the domestic brands and ahead of the global brands.
