| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | SAFEGAS |
| 인증: | ATEX/IECEX |
| 모델 번호: | SG100 |
| 최소 주문 수량: | 1 |
| 가격: | 협상 가능 |
| 포장 세부 사항: | 알루미늄 가방 포장 |
| 배달 시간: | 3-5 일 |
| 지불 조건: | T/T, Western Union |
| 공급 능력: | 100 조각/일 |
| 가스 감지: | 유독가스, 산소, 가연성, VOC 가스 | 탐지 원리: | 전기화학, NDIR, 촉매, PID 등 |
|---|---|---|---|
| 전력 소산: | 독성 가스 <2.5W, 가연성 가스 <4W | 커뮤니케이션 모드: | 4-20MA (3- 와이어), RS485 1 ~ 5V, HART (선택 사항) |
| 무선 전화: | 로라, 4G (선택 사항) | 작동 전압: | 12-24VDC |
| 계전기: | 낮은/하이/오류 경보 릴레이를 포함한 3 개의 릴레이 (선택 사항) | 표시하다: | LED 디스플레이 |
| 작업 온도: | -40 7 ~ 70 ℃ (촉매 센서), -20 ~ 50 ℃ (전기 화학 센서) | 작동 압력: | 86kPa~106kPa |
| 케이싱 재료: | 옵션을 위해 주조 알루미늄, S316 | 케이블 입구: | 1 x ¾ NPT & 1 x M20 케이블 입력 연결 |
| 크기: | 157.8 × 128.8 × 69.6mm | 무게: | 1.0kg |
| 보증: | 1 년 | ||
| 강조하다: | cost-effective flammable gas detector,IP66 waterproof gas detector,dust resistant multi gas detector |
||
| Gas Detected | Toxic gases, oxygen, flammable, VOC gases |
|---|---|
| Detection Principle | Electrochemical, NDIR, Catalytic, PID, etc |
| Measure range | Specified according to application |
| Resolution | Specified according to application |
| Accuracy | ≤±2-5%FS (Depending on the specific sensor) |
| Explosion-proof grade | IECEx: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb; ATEX: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb |
| Protection grade | IP66/68 |
| Power dissipation | Toxic gas<2.5W, flammable gas<4W |
| Communication mode | 4-20mA (3-wires),RS485 1~5V, Hart (Optional) |
| Wireless | LORA, 4G (Optional) |
| Working voltage | 12-24VDC |
| Relay | 3 relays, including low/high/fault alarm relay (Optional) |
| Display | LED display |
| Working temperature | -40℃~70℃ (Catalytic sensor), -20℃~50℃ (Electrochemistry sensor) |
| Working pressure | 86kPa~106kPa |
| Casing material | Die casting aluminum, S316 for option |
| Cable Entries | 1 x ¾ NPT & 1 x M20 Cable Entry Connections |
| Size | 157.8×128.8×69.6mm |
| Weight | 1.0Kg |
| Warranty | 1 year |
Gas Detection CapabilitiesCompany ProfileEstablished in 2010, Shenzhen Yuante Technology Co., Limited is a company that focuses on the design, production and sales of high-end gas detection equipment and system for 16 years. With gas detector as the core product, we have completed production line and solutions according to different industries, such as Oil, Chemical, Medicine, Energy, Environmental Protection, Electronic,Municipal Engineering, Agriculture and Forestry, Household Appliances, etc. Through about 10 years of rapid development, Yuante becomes the influential supplier.
For years, Yuante always insists on the management concept Market is orientation; Innovation is motivation; Quality to survival; Development to growth. With friendly, open and strict corporate culture and standardized management, Yuante gathers a lot of talents, and builds up the management team and R&D team. All the staff cooperates well in product development, production and maintenance, and has a deep understanding of the concept of customer oriented and has the service spirit through the company operation and management, to win the trust and support from customers.
The essence of a detector is the accuracy and faster response. Depending on years of measurement experience and unique solutions, through independent research and development, cooperative development and learning overseas latest technology, Yuante's products are advanced beyond the domestic brands and ahead of the global brands. We are seeking for development and progress constantly, and trying to meet diversified demands from customers.
